Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-800)

A make from the high quality structural 45# steel, Sanxing manufactures, supplies and exports Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-800) that build highways, buildings, workshops, warehouses and more. We have processed the machine to reach 13-15 steps.

More about Hydraulic K Span Arch Sheet Roll Forming Machine (SX-1000-800) : This model operates with 800 mm effective width. The machine with groove depth 114m is equipped with a power set that automatically transports steel sheets.

Main Technical Specifications :

• Length : Approx. 10.3 m
• Width : Approx. 2.25 m
• Height : Approx. 2.30 m
• Weight : Approx. 13000kg
• Axle : Three axles, six tyres
• Wheel/tires : Standard
• Towing :adjustable draw bar height from 80mm-160mm with 80mm round hitch.
• Lighting System : Easily adaptable lighting
• Drive System : All hydraulic
• Fuel tank capacity : 68 liters
• Construction : All steel and burnished aluminum construction, precision forming rollers with hard chrome plating.
• De-coiling Device : 508 mm inside diameter, 5000kg capacity
• Plant : Premium urethane enamel over epoxy primer (white) with buyers' markings on top and side covers
• Panel forming speed : Approx. 18 meters/min
• Curving Speed : Approx. 15 meters/min
• Seaming Speed : Approx. 6 meters/min
• Tables four legs, with rollers, stand separately
• Minimum Radius : 3.65 meters
• Steel Coil Capacity : 1.2 mm nominal ASTM 653 Grade 50, 1.5 mm maximum thickness, 0.80 mm minimum thickness
• Maximum Building Size : 14 meters wide, widths are calculated using liberal code parameters from the International Building Code.
