Hydraulic K Span Arch Sheet Roll Forming Machine (SX-600-305)

Sanxing, the manufacturer, supplier and exporter of Arch roof forming machines in China offers its exclusive Hydraulic K Span Arch Sheet Roll Forming Machine (SX-600-305). Get your own SX-600-305 Kspan Machine built with steel and burnished aluminum. The precision forming rollers are made of tough chrome plating.
More about Hydraulic K Span Arch Sheet Roll Forming Machine (SX-600-305) : Offering a capacity of 2,300kgs, this machine is an engineered with international safety standards.

Main Technical Specifications :

• Length : Approx. 9.00 m
• Width : Approx. 2.25 m
• Height : Approx. 2.30 m
• Weight : Approx. 9000kg
• Axle : Three axles, six tyres
• Wheel/tires : Standard
• Towing : adjustable draw bar height from 80mm-160mm with 80mm round hitch.
• Lighting System : Easily adaptable lighting
• Drive System : All hydraulic
• Fuel tank capacity : 68 liters
• Construction : All steel and burnished aluminum construction, precision forming rollers with hard chrome plating.
• De-coiling Device : 508 mm inside diameter, 5000kg capacity
• Plant : Premium urethane enamel over epoxy primer (white) with buyers' markings on top and side covers
• Approx. 15 meters/min
• Curving Speed : Approx. 13 meters/min
• Seaming Speed : Approx. 6 meters/min
• Tables Four legs, with rollers, stand separately
• Minimum Radius : 3.65 meters
• Steel Coil Capacity : 1.2 mm nominal ASTM 653 Grade 50, 1.5 mm maximum thickness, 0.80 mm minimum thickness
• Maximum Building Size : 26 meters wide, widths are calculated using liberal code parameters from the International Building Code

Sanxing is a professional Arch Roof Forming Machine manufacturer in China. We can provide Kspan machine of various specifications for you to choose from. Additionally, we also provide Ultimate Building Machine Roll Forming Machine, CNC Screw-joint Roll Forming Machine etc. With Sanxing steel construction machines, you can begin your construction project immediately!
