Hydraulic K Span Arch Sheet Roll Forming Machine (SX-914-400)

Sanxing Machinery, an ISO Certified manufacturer, supplier and exporter of Hydraulic K Span Arch Sheet Roll Forming Machines. We bring forth the tough CE certified Hydraulic K Span Arch Sheet Roll Forming Machine (SX-914-400) which comes with a mechanical expansion decoiler, straight panel forming unit and additional accessories. Our product has a panel operating factor of 43% and 13 step rollers.
Benefits :

• Operates at fascinating speed of 15 m/min
• 400 mm effective width

Main Technical Specifications :

• Length : Approx. 10.3 m
• Width : Approx. 2.25 m
• Height : Approx. 2.30 m
• Weight : Approx. 13000kg
• Axle : Three axles, six tyres
• Wheel/tires : Standard
• Towing : adjustable draw bar height from 80mm-160mm with 80mm round hitch.
• Lighting System : Easily adaptable lighting
• Drive System : All hydraulic
• Fuel tank capacity : 68 liters
• Construction : All steel and burnished aluminum construction, precision forming rollers with hard chrome plating.
• De-coiling Device : 508 mm inside diameter, 5000kg capacity
• Plant : Premium urethane enamel over epoxy primer (white) with buyers' markings on top and side covers
• Panel forming speed : Approx. 15 meters/min
• Curving Speed : Approx. 13 meters/min
• Seaming Speed : Approx. 6 meters/min
• Tables Four legs, with rollers, stand separately
• Minimum Radius : 3.65 meters
• Steel Coil Capacity : 1.2 mm nominal ASTM 653 Grade 50, 1.5 mm maximum thickness, 0.80 mm minimum thickness
• Maximum Building Size : 40 meters wide, widths are calculated using liberal code parameters from the International Building Code


Founded in 1992, Sanxing Machinery is an ISO 9001-2000 certified Kspan arch steel roof machine manufacturer in China. Welcome to contact us for further information about our steel construction machines.
