Contact SupplierFEATURES:
- All steel welded structure, vibrating treatment of ageing for removal of internal stress, with good rigidity and stability.
- Torsion shaft forced synchronization of mechanical limit stopper balance, with high precision
- Integrated hydraulic transmission system, large range of speed regulation thanks to transmission of the sliding block, stable and reliable performance.
- Rear stopper and the sliding block have electrical adjustment for their stroke, with manual fine tuning and digital indication.
- Adjustment mechanism of sliding block independent from oil cylinder assembly to enhance sealing effect upper mold is fitted with tilting warp offset mechanism.
- For bending machine from 250t up synchronization mechanism of mechanical or electrical hydraulic transmission is fitted, lower working table is fitted with warp offset mechanism.
- Multi machine combined operation is possible
MODEL | 40/2000 | 63/2500 | 80/2500 | 80/3200 | 100/3200 | 100/4000 | 125/3200 | 125/4000 | 160/3200 | 160/4000 | 200/3200 | 200/4000 | 250/3200 | 250/4000 |
Pressing Force(kn) | 400 | 630 | 800 | 800 | 1000 | 1000 | 1250 | 1250 | 1600 | 1600 | 2000 | 2000 | 2500 | 2500 |
Working Length(mm) | 2000 | 2500 | 2500 | 3200 | 3200 | 4000 | 3200 | 4000 | 3200 | 4000 | 3200 | 4000 | 3200 | 4000 |
Dist between Housings (mm) | 1615 | 2020 | 2015 | 2565 | 2555 | 3105 | 2550 | 3100 | 2550 | 3100 | 2550 | 3140 | 2430 | 3120 |
Depth of Throat(mm) | 200 | 250 | 250 | 250 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 400 | 400 |
Stroke of the Ram(mm) | 100 | 100 | 100 | 100 | 130 | 130 | 130 | 130 | 150 | 150 | 200 | 200 | 250 | 250 |
Approaching speed (mm/s) | 100 | 90 | 90 | 90 | 80 | 80 | 80 | 80 | 80 | 80 | 70 | 70 | 70 | 70 |
Working speed (mm/s) | 8 | 8 | 8 | 8 | 10 | 10 | 8 | 8 | 9.5 | 9.5 | 7.5 | 7.5 | 7.5 | 7.5 |
Returning Speed (mm/s) | 70 | 70 | 70 | 70 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 66 | 66 |
Adj of Ram travel(mm) | 70 | 70 | 70 | 70 | 85 | 85 | 85 | 85 | 110 | 110 | 110 | 110 | 120 | 120 |
Dist between table & ram(mm) | 340 | 335 | 350 | 350 | 380 | 380 | 380 | 380 | 400 | 400 | 435 | 460 | 460 | 460 |
Motor power (kw) | 4 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | 7.5 | 7.5 | 11 | 11 | 15 | 15 | 15 | 15 |
Weight of Machine(kg) | 3000 | 4000 | 4600 | 5500 | 6600 | 8200 | 7300 | 8700 | 8900 | 11500 | 10900 | 13300 | 14500 | 18000 |
LxWxH(mm) | 2100x1150x2000 | 2600x1300x2090 | 2600x1300x2180 | 3300x1300x2200 | 3300x1410x2320 | 4100x1415x2450 | 3300x1460x2450 | 4100x1465x2505 | 3300x1540x2460 | 4100x1540x2650 | 3300x1715x2765 | 4100x1715x2950 | 3300x1980x3020 | 4100x1750x3700 |
