Hydraulic Pushing Machine, Brand Name : Fengliyuan

₹ 21.72 Lakh / 560000 560000 Set

MOQ1 Set(s)
Brand NameFengliyuan
big thrustheavy duty
induction heatinghydraulic pushing
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

We are offering hyraulic pushing machine to expand carbon steel pipe or tube. The main technical parameters of the pipe expanding machine 1. The oil cylinder: ф 320mm,the rod：ф 210mm ，the....

Company Information

Yanshan Fengliyuan Pipe Fittings Equipment Manufacture Co.,Ltd

Member Since 12 Years
Nature of Business Manufacturer
Year of Establishment 2000

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

We are offering hyraulic pushing machine to expand carbon steel pipe or tube. The main technical parameters of the pipe expanding machine
1. The oil cylinder: ф 320mm,the rod：ф 210mm ，the effective trip: 6.5m, pressure：21mpa,2 bars
the maximum thrust of the 2 cylinders: 330 tons; the normal speed: 0—110cm/min ,
the max backward speed: 400cm/min.
2. The pump station：
63scy-plunger pump :2 set, 18.5kw motor: 2 sets (the main working pump)
cb-80 gear pump: 1 set, 11kw motor: 1set (for fast forward and back)
cb-20 gear pump: 1 set, 5.5kw motor: 1set (for lifting the fork gate)
3. The hydraulic valve is integrated oil rout, hydraulic fork gate.
4. The frame for the main engine: 25# channel steel, welded with 43kg steel rail
5. The panel for the main engine: welded with 40mm medium plate
6. Distribution cabinets, operation box 1 set
7. Intermediate-frequency power (power 600kw 380v、220v、50hz)
8 the speed of expanding is 300mm——600mm/min.
