Contact SupplierTechnical Data\
| Motor rating input | \800 W | \
| Motor rating output | \500 W | \
| Volume range (H2O) | \0.001 - 2 l | \
| Viscosity max. | \5000 mPas | \
| Speed range | \3000 - 25000 rpm | \
| Speed deviation | \1 % | \
| Speed display | \LED | \
| Speed adjustment | \stepless | \
| Noise without element | \75 dB(A) | \
| Extension arm diameter | \13 mm | \
| Extension arm length | \160 mm | \
| Process type | \batch | \
| Permissible ON time | \100 % | \
| Dimensions (W x H x D) | \87 x 271 x 106 mm | \
| Weight | \2.5 kg | \
| Permissible ambient temperature | \5 - 40 °C | \
| Permissible relative humidity | \80 % | \
| Protection class according to DIN EN 60529 | \IP 20 | \
| Voltage | \220 - 240 V | \
| Frequency | \50/60 Hz | \
| Power input | \800 W | \
