Padsons MS Inclined Belt Conveyor

NAME OF EQUIPMENT

:

Padsons Inclined Belt Conveyor

MODEL NO.

:

PFBC-4

AVERAGE THROUGHPUT CAPACITY

:

4 TPH

APPLICATION

:

For conveying the seed to various processing machinery.

SPECIFICATION:

MATERIAL OF CONSTRUCTIONS

:

Belt Material – PVC Belt Type: E12/2 U0/V20 Green Endless Conveyor belt:

Roller – Seamless pipe Ø220mm dia. 8mm thick.

• Conveyor will be fitted with imported PVC Belt Type: E12/2 U0/V20 Green Endless Conveyor belt. The belt having slats/flights fitted at the interval of 0.25 meter along the belt and having frill (Side) walls on both sides.
• The best and proven quality belt (Imported) which is suppose to be costliest for trouble free service.
• Rollers and press rollers are made from one piece white polypropylene plastic.
• The top of conveyer is covered by acrylic sheet which prevents spilling of dust etc. into surrounding area.
• The main structure of body is made our of 2.5 mm plate to give typical international look to conveyer.
• The press rollers have taper roller bearings for long life.

CONSTRUCTIONAL FEATURES ALONG WITH LEAFLETS & DRAWINGS

:

a)      All metal dully painted with best quality paint and well finished. All parts will be covered with safety guard.

b)      Feeding hopper having suitable capacity. Base on Horizontal portion of belt conveyor, having centrally discharge system control with screw mechanism.

OTHER DETAILS : Which Makes PFBC 4 “Techno economically” best choice.

SPECIAL TECHNICAL FEATURES:

·         The skeleton is made using heavy structure which gives maximum strength.

·         Whole conveyor to be mounted on a MS channel frame.
