Inconel 617 Wire Mesh Screen

We are offering inconel 617 wire mesh screen.
Inconel 617 wire meshscreen provides the outstanding blend of elevated temperature strength and resistance to oxidation. It causes hefty resistance to the various corrosive conditions and stress corrosion cracking. It strictly resists oxidation at temperatures more than 1800of.
The inconel 617 wire meshscreen is in demand due to its superior corrosion resistance features. It is employed in the catalyst grid hold, ducts and land base gas turbines.
mesh specifications
mesh size 0.2meshinch to 250meshinch
thickness 0.1mm-5.0mm
aperture rate 10%-90%
chemical composition(%) of inconel 617 wire mesh screen:
alloy % ni co cr mo al c mn ti cu s fe
inconel 617 min. balance 10.0 20.0 8.0 0.80 0.05
max. 15.0 24.0 10.0 1.50 0.15 0.50 0.60 0.50 0.015 3.00
physical properties of inconel 617 wire mesh screen:
density ( kgm3) 8.0
specific heat ( jkg.k ) 500
melting point (°c) 1370 - 1400
service temperature(°c) 0 - 870
thermal conductivity ( wm.k ) 16
mean coeff thermal expansion(e-6k ) 16 - 17
tensile strength and impact features of inconel 617 wire mesh screen
operation temperature, of time, hours yield strength, ksi tensile strength, ksi elongation % impact strength, ft-lb
1100 100 46.5 111.5 69 213
1000 51.8 116.5 67 223
1200 100 51.8 114.5 69 191
1000 66.6 133.5 37 35
1300 100 58.7 126.5 38 38
1000 70.5 138.0 33 33
1400 100 58.3 126.5 35 35
1000 56.3 126.0 37 37
properties of inconel alloy 617 wire meshscreen:
1. Hefty resistance to an array of corrosive media
2. Wider resistant to a reducing and oxidizing agents.
3. Tremendous resistance to oxidation at high temperatures.
