Incubators

We are offering incubator bod.
incubatr b.o.d.
(bio-chemical-oxygen demand)
designed for low temperature incubation and routine determination of bio-chemical oxygen demand. Double wall construction. Inner chamber made of richly anodized aluminum or highly polished stainless steel sheet with self supports for wide range of shelf spacing. Supplied with twothree removable perforated shelves. Exterior made out of thick mild steel sheet duly finished in white storving enamel paint or paste mat finishing color combinations. Outer double wall door is provided with magnetic gasket and lock & key arrangement. Inner door made out of clear acrylic sheet allowing inspection of material in the chamber without distributing the chamber temperature. Door operated inner illumination has been provided. The gaps between wall of equipments are filled with glass wool for temp. Insulation. The cabinet is mounted on castors.
temperature is controlled by a sensitive thermostat from 5o c to 50o c +- 1o c. For lower temperature. Working a standard cooling unit with a sealed compressor with protective device has been provided below the chamber for safe and efficient working. Heating arrangement has been made within the chamber for higher temp. Working the temp. Can be regulated within the range by means of a high precision double action thermo-regulator. Inner air circulating system is provided to achieve uniform temperature in the whole chamber. A control panel is provided with various indicators, on-off switch, l shaped thermometer. Supplied with cord and plug etc. The equipments is workable on 220 v ac 50 hz single phase.
model no. inner
chamber size capacity capacity
s.s.101 610 x 455 x 410 mm 4.0cft 112 litre
s.s.102 830 x 505 x 415 mm 6.1cft 171 litre
s.s.103 865 x 565 x 565 mm 10.0cft 280 litre
s.s.104 650 x 580 x 900 mm 12.0cft 336 litre
s.s.105 900 x 650 x 700 mm 15.0cft 420 litre
