We have installed all the requisite amenities, necessary for making safe side deliveries. One can stay assured for high quality of the offered lot as we design and develop it using the best in line raw material and modern work methods. In addition to this, we make sure that the material is sourced from the trusted places only.
| Fiber count | 4 | 6 | 8 | 12 | 16 | 24 | 48 | |
| Outer diameter(mm) | 4.8±0.2 | 5.2±0.2 | 6.2±0.2 | 6.8±0.2 | 7.4±0.4 | 8.2±0.4 | 12.5±0.5 | |
| Nominal weight(Kg/Km) | 19 | 23 | 29 | 38 | 48 | 60 | 128 | |
| Max. tensile strength(N) | Short term | 270 | 330 | 480 | 600 | 660 | 720 | 1200 |
| Long term | 90 | 110 | 160 | 200 | 220 | 240 | 520 | |
| Min. Bending Radius(mm) | Dynamic | 20D | 20D | 20D | 20D | 20D | 20D | 20D |
| Static | 10D | 10D | 10D | 10D | 10D | 10D | 10D | |
| Max. crush resistance (N/100mm²) | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | |
| Temperature range | -20°C~+60°C | |||||||
| Optical Transmission Performance | Singlemode 1310/1383/1550/1625nm | Multimode 850/1300nm | |||
| 9/125μm (OS2) | 62.5/125μm (OM1) | 50/125 μm (OM2) | 50/125 μm (OM3) | 50/125 μm (OM4) | |
| Max.Attenuation(dB/km) | 0.36/0.36/0.25/0.35 | 3.0/0.8 | 2.7/0.8 | 2.7/0.8 | 2.7/0.8 |
| Typ.Attenuation(dB/km) | 0.34/0.32/0.21/0.24 | 2.7/0.6 | 2.5/0.7 | 2.3/0.6 | 2.3/0.6 |
| Bandwidth (MHz/km) | N/A | 200/600 | 500/500 | 1500/500 | 3500/500 |
| 850nm laser bandwidth(MHz/km) | N/A | N/A | N/A | 2000 | 4700 |
| Numeriacl apartue | 0.13±0.01 | 0.275±0.015 | 0.200±0.015 | 0.200±0.015 | 0.200±0.015 |
