Product Details
Company Details

Ovel LED is an high quality indoor stage rental led display, led video wall manufacturer and supplier in China. We are always dedicated to provide the latest stage rental Led display solutions, ODM&OEM service. Welcome wholesales rental led display, rental video wall from us.
Ovel series rental led display with unique modular and front maintenance structure design, concentrated on reducing maintenance trouble.Aluminium DieCasting technology help to achieve a high connection precision.Fantasy series with 8Kg/Panel and 500 x 500 x 80 mm only make it portable and easy to install, dismantle. Different models are available.

Features

Ultra thin & light weight (only 8Kg/panel), portable handy
Die-casting aluminium cabinet design with high precision
Modular design, make it easy to maintain and replace
HD show without water ripple on program broadcasting
Easy to assemble & dismantle with fast locks on each cabinet
High gray level & good colour uniformity with brand IC, led lamp
Energy saving without fans design, exclusive natural cooling effect

Easy to replace and maintain with Front Service Structure, realizing time and labour saving. Just need two small wrenches and few seconds we can take the module out from the cabinet easily and quickly. Design of Fantasy series rental led display are concentrated to pursue high definition and stability stage play effect brings us a visual feast.
High definition and contrast ratio :Compared with traditional white leds, pure black leds can obtain a better color uniformity and higher contrast ratio. Brand LED lamp with black body structure and black lamp mask provides 3000:1 contrast ratio, clearer and more bright-colored image.
The latest calibration Technology : Calibration during aging testing before packing and delivery to improve the color uniformity and brightness.
Low brightness with high grayscale, more delicate display performance : Fantasy rental led display choose the updated control solution and high quality Driver IC to realize brightness and Gray scale adjustment automatically.The latest control solution support pixel-pixel brightness correction to boardcast realistic pictures.

Application of Ovel Series :Ovel series rental led display are widely used in

stage events,
TV station,
Concerts,
Expo Events,
Presentation Hall,
Shopping mall,
Night Club and etc.

All Technical Parameters

Model	Ovel RLS- 3	Ovel RLS- 3.91	Ovel RLS- 4.8	Ovel RLS- 6
Pixel Pitch	3mm	3.91 mm	4.8 mm	6 mm
LED Type	SMD 2020	SMD2020	SMD2020	SMD3528
Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Module Size	192*96 mm	250*250 mm	250*250 mm	192*192 mm
Driving IC	MBI 5124	MBI 5124	MBI 5124	MBI 5124
Pixel Density	111111 pixel	65536 pixel	43264 pixel	25600 pixel/ãï¿½¡
Refresh Rate	≥ 1920Hz	≥ 1920Hz	≥ 1920Hz	≥ 1920Hz
Gray Scale	16 Bit	16 Bit	16 Bit	16 Bit
Brightness	≥ 1200 cd	≥ 1200 cd	≥ 1200 cd	≥ 1500 cd/ãï¿½¡
Scan Way	1/16	1/16	1/13	1/10
Frame Rate	50HZ~60HZ	50HZ~60HZ	50HZ~60HZ	50HZ~60HZ
Viewing Angle	H:140°, V:140°	H:140°, V:140°	H:140°, V:140°	H:140°, V:140°
Cabinet Resolution	128*128 Dots	128*128 Dots	104*104 Dots	80*80 Dots
Material	Die-casting Aluminium/ magnesium	Die-casting Aluminium/ magnesium	Die-casting Aluminium/ magnesium	Die-casting Aluminium/ magnesium
Cabinet Size	57657680mm	50050080mm	57657680mm	50050080mm
Cabinet Weight	9-10 Kg	8Kg	9-10 Kg	9-10 Kg
IP Rating	IP31	IP31	IP31	IP31
Max. Power Consumption	210W/Panel	210W/Panel	190W/Panel	130W/Panel
Avg. Power Consumption	70W/Panel	70W/Panel	65W/Panel	40W/Panel
Control System	Nova/Linsn	Nova/Linsn	Nova/Linsn	Nova/Linsn
Operation System	Window xp/7/8/10	Window xp/7/8/10	Window xp/7/8/10	Window xp/7/8/10
Working-Temperature	-20~60	-20~60	-20~60	-20~60
Working Humidity	10%~90% RH	10%~90% RH	10%~90% RH	10%~90% RH
Input Voltage	AC 110~220 V (±5%)	AC 110~220 V (±5)	AC 110~220 V (±5%)	AC 110~220 V (±5%)
Blind spot rate	≤0.01%	≤0.01%	≤0.01%	≤0.01%
MTBF	35000 Hour	35000 Hour	35000 Hour	35000 Hour
Lifespan	100000 Hour	100000 Hour	100000 Hour	100000 Hour
