Induction Forging Machine Gys-40ab

Induction Forging Machine Gys-40ab
~major features:
- this equipment adopts the igbt inverter circuit in parallel connection, which has high load adaptability.
- it has such feaures as high power, fast heating speed, high efficiency and easy operation.
- as compared with other heating modes, it can significantly promote the economic benefits, improve the quality of heated work pieces and save the energy and material, alleviate labor intensity and improve the production environment.
- it has super small size, which can save the production space by 10 times.
- it is safe and reliable, and requires no equipments of ten thousand voltage, and thus can ensure the safe operation.
- the comprehensive full load design is available for 24-hour continuous operation.
Application of induction heating equipment:
a. Heating (hot forging, hot fitting and melting):
b. Heat treatment (surface quench):
c. Welding (braze welding, silver soldering and brazing)
d. Annealing (tempering and modulation)
parameter:
~model gys-40ab (three phase)
work power 220v-520v
maximum input current 65a
output power 40kw
fluctuating frequency 20-50khz
output current 400-1800a
the flow rate of cooling water 0.08-0.16mpa 9lmin
water temperature protection point 50c
product size main :780x370x620 mm
transformer : 510x260x410 mm
net weight main : 54 kg
transformer : 32.5 kg
