Induction Melting Furnace

2.Production Description:
1)Steel Shell Intermediate Frequency Induction Furnace for melting
2) Steel shell hydraulic tilting
3) Melting steel, iron,stainless steel
4)0.15-12 tons capacity
3.Usage: Medium Frequency Induction Furnace Mainly used in melting steel, iron, copper, aluminum and alloy, is with high melting efficiency, good electricity saving effect, good metal component uniformity, less burning loss, speedy temperature rise, easy control of temperature, is suitable to all kinds of metal melting.
4.Characters and Advantages:
1) Constant power output, speedy melting, good electricity saving efficiency.
2) Zero-voltage sweep-frequency style start, adapts to requirement of frequently start.
3) Comprehensive protection functions, such as overcurrency protection, overvoltage protection, current-limiting protection, voltage-limiting, water-break protection, and default protection, equipment runs reliably under premise of melting speed guarantee.
4) Easy to operate, suitable for all casting process.
5. Package: Plywood cases and nude
6. GW Series Melting Furnace Technical Specifications:
Rated Capacity
(T) Rated Power (KW) Power Input Power Output Transformer(KVA)
Inlet wire Voltage (V) Inlet wire Currency (A) Medium Frequency Voltage (V) Rated Power(Hz)
0.15 100-160 3N-380 160-260 750 1-2.5 120,160
0.25 160-250 3N-380 260-410 750 1-2.5 200,250
0.35 200-400 3N-380 320-650 750 1-2 315,400
0.50 350-500 3N-380 580-830 750 1-1.5 400,500,630
0.75 400-600 3N-380 650-1000 750 0.8-1 500,630,800
1 600-800 3N-380 1000-1330 750 0.6-1 800,1000
1 600-800 3N-660 670-900 1200 0.6-1 800,1000
1.5 800-1200 3N-660 900-1330 1200 0.5-1 1000,1250
2 1000-1500 3N-660 1120-1680 1200 0.5-0.8 1250,1600
3 1500-2500 3N-660 1680-2800 1200 0.3-0.6 1800,2500
5 2500-3500 6N-660 2800-3900 1200 0.2-0.5 3150,3600
10 4000-6000 6N-1250 2400-3600 2200 0.2-0.4 5000,6500
12 5000-7000 6N-1250 3000-4200 2200 0.2-0.4 6300,8000
