Industrial DIN-Rail Managed Ethernet Switches (6TP+2F+4G)

Industrial DIN-Rail Managed Ethernet Switches (6TP+2F+4G) is provided with advanced network managed function, like as : SW-Ring redundancy ring network, VLAN, Trunking, Quality of Service, Speed control, port mirroring, fault alarm, etc. We are distinguished Manufacturer, Supplier and Exporter of Industrial DIN-Rail Managed Ethernet Switches (6TP+2F+4G) from Chennai.  The offered Industrial DIN-Rail Managed Ethernet Switches (6TP+2F+4G) is an industrial grade, managed and redundancy Ethernet switch. It has a recovery time of <20ms.

Features

• Support IEEE802.3, IEEE802.3u, IEEE 802.3x, IEEE802.1Q, IEEE802.1p, IEEE802.1D, IEEE802.1W
• SW-Ring ring network patent technology (Fault recovery time<20ms
• Support RSTP, way exchange time<1s Support WEB configuration
• Support MAC address learning, aging automatic
• Support port status display, data update.
• Support static and dynamic IGMP
• Support flow statistics
• Support bi-directional port mirroring

Technology

• Standard : Support IEEE802.3, IEEE802.3u, IEEE 802.3x, IEEE802.1Q, IEEE802.1p, IEEE802.1D, IEEE802.1W
• Protocol : ARP, ICMP, TCP, UDP, DHCP, DNS, HTTP, Telnet, SW-Ring, RSTP, SNMP
• Flow control : IEEE802.3x flow control, back press flow control

Function

• Switch function : SW-Ring, QOS, 802.1QVLAN, RSTP, SNMP,
• Port trunking, static multicast filter, port mirroring, bandwidth
• Management, broadcast storm control, port flow statistics,
• Upgrade online, up and download configuration file, user name access system
• SW-Ring : Support Single, Couple, Chain, Dual homing

Exchange Attribute

• 100M forward speed : 148810pps
• 1000M forward speed : 1488100pps
• 100M maximum filter speed : 148810pps
• 1000M maximum filter speed : 1488100pps
• Transmit mode : store and forward
• System exchange bandwidth : 5.6G
• MAC address table : 8K
• Memory : 1M

Interface

• Electric port : 10Base-T/100Base-TX auto speed control, Half/full duplex and MDI/MDI-X auto detect
• 100M optic fiber port : 100Base-FX, SC/ST connector, support single mode (20/40/60/80Km optional), multi mode(2Km)
• Wavelength : 1310nm, 1550nm
• 1000M fiber port : 1000Base-FXSFP port
• Console port : debug serial port carry out CLI command
• Alarm port : 2bit 7.62mmTerminal block
• 1 channel relay alarm output
• Load ability : 1A@24VDC

LED Indicator

• Run indicator : Run
• Interface indicator : Link(1~8/G1~G2)
• Power supply indicator : PWR1, PWR2
• Alarm indicator : Alarm

Power Supply

• Input voltage : 1248VDC
• Input method : 4 bits 7.62mm terminal block
• Overload current protect : 4.0A(DC) or 5.0A(AC)
• Support DC dual power supply alarm input

Consumption

• Unload consumption : 5.1W@24VDC
• Full load consumption : 8.0W@24VDC
• Installation : DIN rail, wall mount
• SizeW×H×D : 138mm×53mm×110mm
• Weight : 720g

Industry Standard

• CE, FCC, RoHS, PAL, UL508(Pending)
• EMI : FCC Part 15, CISPR (EN55022) class A
• EMS : EN61000-4-2 (ESD) , Level 4
• EN61000-4-3 (RS) , Level 3
• EN61000-4-4 (EFT) , Level 4
• EN61000-4-5 (Surge) , Level 4AC power supply

Warranty : 5 years
