Industrial Sliding Doors

We are offering industrial sliding doors. Industrial sliding doors are widely used in a variety of modern industrial plant, with good looks, open stable, safe, reliable, low noise, high strength, good sealing and insulating performance, saving floor space occupancy and improve production efficiency significantly features. Double door material selection embossed galvanized steel, the surface pressure of a uniform cylindrical stripes, door surface treated polyester, color white, almonds, brown core material is polyurethane, the back door equipped with steel reinforcing tape system.
Industrial sliding doors dimensions: width 2440mm 12000mm height: 2130mm 300mm
sliding door thickness: 40mm, thermal resistance coefficient r = 14.96,18.25
rail: there are 2 inches (51mm) and 3 inches (76mm) orbit are two, all using 1.5 3mm thick galvanized steel. Standard rail, leo, vertical and diagonal for liter.
Balancing system: external torsion spring balance system, torsion working life of 50000-100000 times the duty cycle.
Seal: the bottom of the u-shaped vinyl seal, moisture and water infiltration, side, top, grooved sealing, for inter-connection points and seal the door.
Channel wickets: needed when the door is smaller than the width of 5500mm, can be equipped with a variety of sizes of channel wickets
observe small window: you can choose a variety of sizes as required observation window.
Door wind load: 180kg m
industrial opener: industrial sliding doors special opener, power: 250w 330w
transmission: direct and indirect chain drive shaft drive
output torque: single-phase 50nm, three-phase 60nm
the maximum weight of the door: single-phase three-phase 700kg 350kg
limit mode: machinery and electronic
motor speed: 1400rpm
speed: 133mm s (uni8612 standard)
start times: 100 times 24 hours
working temperature: -15- + 60
deceleration mode: gear
manual operation: the operating chain achieve mechanical and electrical clutch, for manual operation. Also you can achieve fast rope manual operation mode.
