Industrial X-Ray Wheel Inspection Radiography Machine

Industrial X-Ray Wheel Inspection Radiography machine 2000Y     First NDT company who certified by ISO9001 quality department 2001Y     Fist wheel RTR system research manufacturer 2002Y     First piston motor RTR system research manufacturer 2005Y     First NDT company who used solid HV generator into Chinese x ray market 2006Y     Research SAW pipe inspection system which can detect max 3500mm pipe 2008Y     China first set Li-ion battery inspection system manufacturer 2009Y     Build new"Annual hundred set RTR system producing Factory" 2010Y     Single polar/Bipolar metal ceramic x ray tube programme proved by Chinese government 2011Y     First 6Mev linear accelerator research and manufacture by DNDT successed 2012Y     New age X ray generator/High voltage power supply used in China market and got good feedback  System Technical Targets: 1． Parameters of inspected wheel: Model:wheel Dimension:12~22inches Material:Al Defects:Air hole, slag inclusion, loosen, zoom hole, pinhole and so on 2．Penetration ability of X-ray machine: Film:Fe  28mm   Al  160mm Radiography:Fe  18mm   Al  100mm 3．System resolution:30p/cm 4．System sensitivity: Dynamic sensitivity:1.8~2.5% Statistic sensitivity:0.8~1.6%          Statistic sensitivity:Images with integral noise-reduction process
