Industry CNC Engraving Machines GY-1812, Certification : CE, SGS

We offer cnc router machine.
Working travel:-
X axis 1200 mm Y axis 1800 mm Z axis 230 mm
Table size
1200 mm*1800 mm
Maximum speed
X Y axes 60m/min
Spindle
Voltage: AC380v Frequency:400Hz
Italy HSD
Speed:24000r/min Power:8kw
Pressure
Air-blow pressure 0.4 MPa Tool hold Pressure 0.7 MPa
Pressure protection
No less than 0.7
Dust collecting power
3.0kw
Vacuum power
5.0kw (phenol aldehyde laminated cloth board)
Total power
23.0kw
Mechanism size
Area:1.8m*3.3m Height:1.5m Weight:850kg
Japanese servo motor
Large torque, which ensures stable operation, low noise, accurate position. The idle strake speed can be more than 60m/min.
Tool storage
8 tools
Diameter of cutter head
3.175mm, 6mm, 12.7mm.
Cubage
18.0 CBM
