Inverted Fluorescence Microscope, Head Type : Trinocular Head

MODEL: INV-3i FL
STANDARD FEATURES
Infinite Optical System
Trinocular Head Inclined at 30°, Interpupilary Distance 48-75mm
Nosepiece Quintuple Nosepiece Condenser ELWD Condenser NA0.3, LWD72mm(without Condenser 150mm)
Phase Annulus 10X-20X、40X Phase Annulus Plate(Fixed)
Attachable Mechanical Stage, X、Y Coaxial Control, Moving Rang 120X78mm
Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range up 8mm, down 3mm
Halogen Lamp 6V/30W
Filters: Blue, Green and Ground Glass, Diameter 45mm
Reflected Light Source: Mercury Lamp 100w
Protection barrier: Barrier to resist Ultraviolet light
Filters: Blue Filter(Excitation 460-490nm) and Green Filter(Excitation 480-550nm)
OPTICAL COMBINATION
EYE PIECES: Extra Wide Field Eyepiece EW10X/22
OBJECTIVES:
LWD Infinite Plan Objective 4X/0.1, WD17.3mm
