PANCHAL 100-500kg 32mm Pillar Drill Machine, Certification : ISO 9001:2008

our huge product basket commensurate to the international quality standards and thus, customers can rely on us for the quality. being a supplier of 32mm pillar drill machine, we strive to deliver high quality and cost effective products in the market.

details:

• drilling capacity in steel - 32 mm
• no. of spindle speed - 115-210-325-520-660-1090-1750-2890
• spindle nose taper - mt-4
• spindle center to column - 254 mm
• spindle travel - 158 mm
• maximum distance between spindle to table - 625 mm
• maximum distance between spindle to base - 930 mm
• working surface of table - 326 x 326 mm
• working surface of base - 347 x285 mm
• column diameter - 87 mm
• base of machine - 570 x 365 mm
• overall dimension of m/c. - 1600 x 650 x 520
• motor speed - 1440 rpm
• motor 3 phase induction a.c. - 1 h.p.
• weight of machine (approx) - 250kg.
