1. Power sets below , the elevating movement structure and the entire shroud structure to make the working conditions obviously safe.
2. Innovative pneumatic -- manual pivot angle lock mechanism makes the angle localization to be more accurate and reliable, it would be not easy to become less crowded.
3. Power place abutting engine case back structure makes the saw blade path to be steady and organization compact.
â–² Sawing cutting length: 400~4500 mm
â–² Sawing cutting width: 150 (200) mm
â–² Sawing cutting height: 150 (120) mm
▲ Motor power: 2×2.2kw
â–² Spindle rotation speed: 2800r/min
▲ Saw blade dimension: ф500×ф25.4×4 mm
▲ Operating angle: - 45°~45°
â–² Operating air pressure: 0.6~0.8MPa
â–² Working voltage: 380V
▲ Overall dimension: 5650×1030×1360mm
â–² Weight: 1650kg
