JD2204 Galvo Scanner For Laser Marking Machine

₹ 90.50 / 1000 1000 Set

MOQ1 Set(s)
Total Carbohydrate18 months
Scale Drift< 40PPM/℃
CertificateCE, ROHS, ISO9001
Beam Displacement13.4mm
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Product Details

Total Carbohydrate18 months
Marking speed5000mm/s
Beam Displacement13.4mm
Zero Drift< 15μRad./℃
CertificateCE, ROHS, ISO9001
InterfaceDigital or analog
Beam input aperture10mm
Scale Drift< 40PPM/℃

Main Features:
1. Lower temperature and stronger anti-interference .
2. An economic galvanometer scanning head .
3. It mainly used in high speed and marking on the fly.
4. It has a superior performance of zero drift, higher speed, lower temperature and stronger anti-interference.
5. With 10mm beam input aperture
6. 18 months warranty
7. With CE, ROHS, ISO9001
8. We have branch office in Korea, Germany and India
9. MOQ: 1 set
10. Payment term: TT 100%, Paypal, Western Union
11. Lead time: Within 3 days after receiving the payment
Motor specification:
Working Temperature 0-45℃
Linearity 99.9%
Setting Time ≤ 0.4ms
Scale Drift
Zero Drift
Long-term Drift Over 8 Hours
RMS Current 3.0A
Peak Current 15A(Max)
Maximum Scan Angle ±15°
Storage Temperature -10 to +60℃
Resolution 12μrad
Repeatability 8μrad
Input Aperture 10.0mm
Beam Displacement 13.4mm
Motor Weight 120g
Frequency ≤800Hz
