JGH-103F Co2 Flying Laser Engraving Machine

3W ultraviolet laser marking machine belongs to the series of laser marking machines. The difference is that it was inspired by 355um ultraviolet laser machine.The machine adopts the third order intracavity frequency doubling technique, compared to the infrared laser, minimal focal sp 355 uv light, can largely reduce the material deformation and mechanical processing heat affected small, mainly used for super fine large table, sculpture, especially suitable for used in food, medicine packaging material marking, microporous, glass material of high speed divided and complex graphics on silicon wafer cutting and application field. Specification Model JGH-103F Machine Name CO2 Flying Laser Engraving Machine laser Length 1064um Laser Power 10 / 30 / 50 / 100 / 150 W Laser Repetition Rate ≤20KHz Minimum Linewidth 50u m Marking Speed 250 characters/second (Roman font, 1mm high) Markup characters 0.3mm Marking Depth ≤0.5mm(According to the materials) Repeatability Precision ±0.003mm Power Stability (8h) ＜±1%rms Marking Range 110mm X 110mm.175mm X 175mm 300mm X 300mm(Optioanl) Beam Quality M2＜5(@25A) Machine size About 650×850×1500mm Power Demand 220V±220V/50Hz/30A KW ＜1.5KW Cooling Air or Water Machine Weight About 60KG Product Features: 1. Juguangheng CO2 Flying Laser Engraving Machine has portable design and desktop design, which can be reasonably distributed according to user needs.
