Kaplan Turbine Test Rig, Voltage : 440 V / 3-phase (Typical)

The Kaplan Turbine Test Rig is a precision laboratory setup designed to study the performance and characteristics of Kaplan turbines under controlled conditions. The rig is suitable for hydraulic and mechanical engineering experiments, allowing students, researchers, and engineers to analyze turbine behavior at various flow rates and head conditions.

It operates with a capacity of 1 HP or 1 KW and a rated speed of 1000–1050 RPM, simulating real-world turbine performance. The system accommodates a discharge capacity of 1000–1500 LPM and a net head ranging from 5 to 10 meters. A 5 HP motor powers the setup, and a 300 mm brake drum is integrated for torque and efficiency measurements. The test rig provides hands-on experience in understanding turbine mechanics, efficiency, and load characteristics.

Key Features

• Operational capacity: 1 HP or 1 KW

• Rated speed: 1000–1050 RPM

• Discharge capacity: 1000–1500 LPM

• Net head adjustable from 5 to 10 meters

• Powered by a 5 HP motor

• Brake drum diameter: 300 mm for torque measurement

• Ideal for performance analysis and efficiency testing

• Compact and durable laboratory design

• Provides practical insights into Kaplan turbine operations

Applications

• Hydraulic engineering laboratories for turbine performance studies

• Research on flow characteristics and efficiency of Kaplan turbines

• Educational demonstrations for engineering students

• Industrial R&D for small-scale hydro power setups

• Performance testing under variable discharge and head conditions
