Standards compliance:
mss sp-81, jbt 8691
face to face dimension: mss sp-81
pre-temperature rating: ansi b16.34
flanged dimension: ansi b16.5, din2533; jb79; gbt 9113; hg20592
inspect & test: api 598, gbt 13927; jbt 9092
body,ci,di,carbon steel,stainless steel:
wedge:ss304,ss316,bronze.
Seat,epdm,ptfe
stem,ss410,ss304,ss316
stem packing ptfe graphite composite.
Cast iron:
cast iron a126 gr. B body and bonnet.
F304 stem & gate, resilient or metal seating
stem packing ptfe graphite composite.
Available also in low temperature steels, low alloy steels, stainless steels, duplex type stainless steels and other exotic materials.
Various trim materials available to suit service conditions.
type:direct-acting
material:stainless steel
connection form:lug type
pressure:low pressure
actuator:manual
seal surface:parallel gate valve
thread position of valve rod:outside gate valve
usage:regulation
standard:din
size:dn50 to dn1200
