Specification:
| Model | LM6NC3 | LM12NC3 | LM25NC3 | LM50NC3 | |
| Focal length（mm） | 6 | 12 | 25 | 50 | |
| Image size（mm） | 1/2"（Φ8） | 1/2"（Φ8） | 1/2"（Φ8） | 1/2"（Φ8） | |
| Iris range（F-stop） | F1.8〜F16 | F1.8〜F16 | F1.8〜F16 | F1.8〜F16 | |
| Focusing range（m） | 0.1〜∞ | 0.15〜∞ | 0.2〜∞ | 0.3〜∞ | |
| Control | Iris | Manual | Manual | Manual | Manual |
| Focus | Manual | Manual | Manual | Manual | |
| Shooting range at M.O.D. | 117（H）×95（V） | 89（H）×66（V） | 56（H）×42（V） | 39（H）×29（V） | |
| Angle of | 1/2 inch | 58.8×44.9 | 30.4×22.8 | 14.6×11.0 | 7.0×5.3 |
| View （degree） |  1/3 inch | 44.9×34.0 | 22.8×17.2 | 11.0×8.2 | 5.3×4.0 |
| Resolution（Center, Corner） | 120lp/mm，100lp/mm | 120lp/mm，100lp/mm | 120lp/mm，100lp/mm | 120lp/mm，100lp/mm | |
| Distortion（TV） | −2.1% | −0.90% | −0.17% | 0.01% | |
| Back focus in air（mm） | 15.2 | 15.2 | 15.0 | 21.2 | |
| Mount | C-mount | C-mount | C-mount | C-mount | |
| Filter thread（mm） | M37.5×P0.5(Option) | M27×P0.5 | M27×P0.5 | M35.5×P0.5 | |
| Size（mm） | Φ39×64.3 | Φ30×58.5 | Φ30×47 | Φ40×66 | |
| Weight（g） | 99 | 90 | 75 | 50 | |
| Temperature range | −10℃〜＋45℃ | −10℃〜＋45℃ | −10℃〜＋45℃ | −10℃〜＋45℃ | |
Specifications are subject to change without notice.
