STIPL Stainless Steel Laboratory Hydra Pulper

₹ 1 - ₹ 10,000 / Unit

MaterialStainless Steel
Brand NameSTIPL
UsageFor Pulping of Dry Pulp Sample in Laboratory Scale
Country of OriginIndia
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Company Information

Member Since 2 Years
Nature of Business Manufacturer
GST No. 09AAQCS9142J1ZM

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

MaterialStainless Steel
Country of OriginIndia
UsageFor Pulping of Dry Pulp Sample in Laboratory Scale
Brand NameSTIPL
Glass WoolStainless Steel 316 Vessel Duly Insulated with Glass Wool
Container Capacity10, 30 & 50 litres
BeltsPropeller V-belts Drive and a Circulates the Stock Effectively to Disintegrate Material Rapidly
Consistency5% Maximum (higher Consistency Pulper is also Available Consistency Range upto 35%
Speed500 RPM
Power SupplyElectric Motor 3 Phase 440V, AC.

Definition : The laboratory hydra pulper is used for the de-fibreing of the virgin and secondary fiber in laboratory trial of different raw material for making pulp to measure properties, before making commercial production . A suitable and standard apparatus for making pulp, minerals fibres pulp like mica, asbestos etc.

Device Description : the unit consists of a pulping container with a rotor at the bottom driven by a V belt in the lower part of the unit . the electric motor has an adjustable frequency convertor to regulate the rotational speed . a ball valve at the bottom drains the pulp . an acrylic cover prevents injuries during the pulping process . A smaller opening in the cover allows extra content during pulping.

Test Description : the pulp is torn out by hand into about 2 x 2 cm large pieces and soaked with water , then the pilper is activated to mix the pulp and take apart the single fibres without destroying their structures to a homogenous suspension
