Ladle Refining Furnace

₹ 90,500 / Set

MOQ1 Set(s)
ConditionNew
Number Of FlowerIndustrial Furnace
Total Carbohydrate3 years
Brand NameHani R
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Company Information

Member Since 7 Years
Nature of Business Supplier
Year of Establishment 1981

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Number Of FlowerIndustrial Furnace
ConditionNew
Total Carbohydrate3 years
Ladle capacity35 T
After-sales Service Providedyes
Brand NameHani R

Ladle Metal Refining Melting Furnace LF Metal Melting Furnace

Ladle Refining furnace

Ladle refining furnace is used for refining Black metal and nonferrous metal. The purpose of using it is to obtain higher performance target metallic materials. According to the different refining way, refining furnace can be divided into XX kinds.

Ladle furnace, also known as refined-smelting ladle furnace, keeps molten steel at the right temperature by variable arc heating. Slag-making material such as Lime, fluorite can be used for slagging, Blowing argon into the bottom of the furnace can wash molten steel. All of these will be removing inclusions from steel. The capacity range of Ladle durance is 10-150 tons. It is suitable for refining molten steel produced by intermediate frequency furnace or the arc furnace.

Ladle Refining Furnace Parameter

Main Parameter
Rated capacity	Ladle diameter (mm)	Rated capacity of transformer(KVA)	Electrode diameter(mm)	Electrical distribution circle diameter(mm)	Heat up rate of molten steel(℃/mm)
18	2200	3200	250	460	≥3
25	2600	3200	250	460	≥2.5
25	2600	4000	300	500	≥3.5
30	2700	5000	300	500	≥4
40	2900	6300	350	650	≥3.5
40	2900	7000	350	650	≥4.5
50	3000	9000	350	650	≥3.5
60	3150	10000	350	680	≥3.5
60	3150	12500	400	700	≥4.5
70	3200	11000	400	700	≥3
70	3200	15000	400	700	≥4.5
80	3300	15000	400	700	≥4
90	3400	16000	400	700	≥3.5
100	3500	16000	400	700	≥3.5
120	3600	20000	450	800	≥4
130	3700	20000	450	800	≥3.5
