Large Fragment - Locking- Broad LC-DCP Safety Lock Plate 4.5 /5.0

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

The Broad LC-DCP Safety lock Plate 4.5/5.0 is indicated for fixation of various long bones, such as the humerus, femur and tibia and for use in fixation of peri-prosthetic fractures, osteopenic....

View More Details

Send Enquiry

Company Information

NARANG MEDICAL LIMITED

Naraina, Delhi

View Number

Member Since 16 Years
Nature of Business Retailer
Year of Establishment 1953

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

The Broad LC-DCP Safety lock Plate 4.5/5.0 is indicated for fixation of various long bones, such as the humerus, femur and tibia and for use in fixation of peri-prosthetic fractures, osteopenic bone and fixation of non-unions or malunions in adult patients.
All holes accommodate Cortex Scerw Φ 4.5mm, Self tapping and safety lock Screw Φ 5.omm.

No. of Holes	Length in mm	TITANIUM
5	98	Ti-SF-151.105
6	116	Ti-SF-151.106
7	134	Ti-SF-151.107
8	152	Ti-SF-151.108
9	170	Ti-SF-151.109
10	188	Ti-SF-151.110
11	206	Ti-SF-151.111
12	224	Ti-SF-151.112
13	242	Ti-SF-151.113
14	260	Ti-SF-151.114
15	278	Ti-SF-151.115
16	296	Ti-SF-151.116
18	332	Ti-SF-151.118
20	368	Ti-SF-151.120
22	404	Ti-SF-151.122
24	440	Ti-SF-151.124

No. of Holes	Length in mm	STAINLESS STEEL
5	98	SF-151.105
6	116	SF-151.106
7	134	SF-151.107
8	152	SF-151.108
9	170	SF-151.109
10	188	SF-151.110
11	206	SF-151.111
12	224	SF-151.112
13	242	SF-151.113
14	260	SF-151.114
15	278	SF-151.115
16	296	SF-151.116
18	332	SF-151.118
20	368	SF-151.120
22	404	SF-151.122
24	440	SF-151.124
