Laser Photos Engraving Machine

We are offering laser photos engraving machine for crystal wood.
Laser Photos Engraving Machine For Crystal Wood
G/Fiber laser marking machine,laser embroidery machine for textile,flexible material,industrial material,wood,acrylic,organic glass,metal,sheet metal and other similar metal and non-metal materials to easy your business
When e-mail Kelly Li for price list,product specifications and working video,please ask the following questions at first in order to recommend the suitable machine to you:
What machine do you need?Laser cutting machine,laser engraving machine,laser marking machine,or laser embroidery machine?
Which material do you want to cut,engrave,mark or embroidery?(your industry)
What's your target working area?(the length and width of your raw materials)
Are you end user,distributor or agent?
Laser Engraving Machine Specifications:
��Working size and laser power can be customized according to requirement.
(1)Model No.:
a.JG-7040SG b.JG-8550
(2)Laser tube:
a.CO2 DC Glass Laser Tube b.CO2 RF Metal Laser Tube
(3)Laser power: 30W,50W,65W
(4)Working area:
a.700mm�400mm b.850mm�500mm
(5)Working table:
a.Honeycomb and aluminous strip panel double-face working table(Automatic up and down distance: 0-150mm)
b.Zinc-iron honeycomb working table
(6)Engraving speed:
a.30000mm/min b.72000mm/min
(7) Repeating Location Accuracy: ±0.1mm
(8) Motion System:
a.Step Motor, Off-line motion control system, LCD screen b.Servo Motor, Off-line motion control system, LCD screen, Synchronous belt drive
(9)Cooling System: Water cooling and protection system
(10)Power supply: AC220V±5%/50Hz
(11)Support format: AI, BMP, PLT, DXF, DST, etc.
(12)Select collocation: Mini air compressor, 550W exhaust fan
(13) Optional collocation: Rotary attachment, Red light pointer, Constant temperature water
Recommended Model 1: JG-8550 Laser Engraving Machine
Stable and durable structures, deformation resistance is strong.
Synchronous belt transmission technology and semi-closed-loop structure, engraving with high precision and fast speed. (engraving speed up to 800-1000mm/s)
Equipped with 30W RF metal laser. Output beam of high quality, excellent power stability, long life, low use-cost, maintenance-free, and high efficiency.
With smarting nesting function, material utilization is higher.
Recommend Model 2:JG-7040SG Laser Engraving Machine
Honeycomb and aluminous strip panel double-face working table is suitable for processing a variety of materials.
Electric lift platform and auto-focusing, easy and flexible operation to meet different processing demand.
Equipped with Rotary attachment for engraving cylindrical objects.
Complete exhaust and filtering of cutting/engraving emissions possible.
Application:
Applicable Materials: Wood, Acrylic, Plywood, MDF, Leather, Glass, Plastic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, Marble, Granite Tile, ABS Double Color Board, Organic Glass, PVC, Paper, Paperboard, Cardboard, Marble, Bamboo, Balsa, Rubber Sheet, etc.
Applicable Industries: Advertising, Signs, Gifts & Crafts, Promotional Items, Plaques, Trophies, Awards, Precise Ornaments, Souvenirs, Models, Architectural Models, Furniture, etc.
GoldenLaser�s Software Presentation:
a. Our software is compatible with BMP, AI, PLT, DST, DXF formats;
b. Seamless connection process for different designs from CorelDraw, AutoCAD, etc;
c. Offline control and large memory for data storing, realize the offline control and batch of production work;
d. One computer control multi-machines for decreasing the invest costing and labor force;
e. 5 inches LCD display screen for easy and convenient operations.
