Laser Pipe Cutter

We are offering laser pipe cutter.
brief introduction
p6012t or p9012 laser pipe cutter, is your first choice of equipping pipes industry. P6012t forms serialization, which could meet the need of cutting various lengths and pipe diameters materials, featured by easy controlling, high automation, high speed, high precise, fit for large scale industry manufacture.
full description
1 formation by only one-shot cutting without further burring elimination
2 flexible process, automatic loading and unloading.
3 basically maintenance-free.
4 able to work around the clock with high cutting precision but low operation cost.
5 customized is available
accessible material:
1round pipe 2 square pipe 3 oblate pipe 4 elliptical pipe
maximum process range:
1 maximum pipe length :6000mm
2 permissible diameter(for round type ):20-160mm
permissible diameter(for square type ):20-120mm
3 permissible thickness of pipe wall
carbon steel:0.2mm-16mm
stainless steel: 0.2mm-8mm
aluminum : 0.2mm-6mm
________________________________________
technical specification:
type key specification
processing pipe（d×l） φ20-φ180mm×6000mm
x axis stroke 6050mm
y axis stroke 200mm
u axis stroke 3000mm
a,b,c axis stroke unlimited rotation
z axis stroke 150mm
x/y/u axis location accuracy ±0.05mm/n
x/y/u axis repeated location accuracy ±0.03mm
x/y axis max. Acceleration 0.5g
x/y single axis max.location speed 50m/min
cnc system pa8000
worktable max.load 100kg
machine tool weight 7000kg
dimension（l×w×h） 12000mm×5000mm×2500mm
