Laser Scanner

Light source type optical imaging; the wave length is 620mm.
Trigger mode automatic
scanning mode single-line scanning
scanning speed 300times s
resolution ≥4mil
printing contrast ratio the lowest reflectivity difference is 30％.
Bit error rate 150million
input voltage 5vdc±0.25v
power 250mw (work): 500mw (momentary maximum)
current 50ma (work): 100ma (momentary maximum)
standby current 45ua
light intensity 3000-12000lux
depth of field 10mm-630mm
scanning angle ±65°±42° (left and right, front and back, rotation)
decoding capacity cupceanjan, upcean with supplemental, uccean 128, code 39, msi, code11
code 39 full ascii, code 39 trioptic, code 128, code 128full ascii
codabar, code93, discrete2of5, iata, rssvariants, codabar, chinese2of5,
international general dimensional barcodes, e.g. Inteleaved25, interleaved2of5,china postal service code and so on
promotion mode buzzer and led indicator
cable interface micro usb; usb
external dimensions l*w*h: 5*3.7*2.2cm
weight 30g(excluding cables)
cable standard straight line,1.8m
interface type micro usb
hull material abs+pc
temperature 0℃ to 50℃ (work): -40℃ to 60℃ (storage)
setting mode manul (scanning and setting barcodes according to the sequence)
safety regulations laser safety class: en60825-1, class 1, state level-i laser safety standard
emc: en55022,en55024
electrical safety: en60950-1
packaging level: ip52
