Lathe machine

Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Features : NAG series all geared head SS & SC precision lathe machine with automatic threading in inches, mm, dp, etc., hardened bed, 4 jaw & 3 jaw chucks, taper turning attachments and all standard accessories

View More Details

Send Enquiry

Company Information

Al Gouri Machinery Trading L.L.C.

Dubai

View Number

Member Since 10 Years
Nature of Business Supplier

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

MODEL	NAG 6	NAG 8	NAG 10	NAG 12	NAG 10 H	NAG 12 H
Height of center	200	300	300	300	375	375
Width of bed	250	350	350	350	450	450
Admit between center	1000	1500	2000	2500	2000	2500
Swing dia in gap	580	800	800	800	1075	1075
Swing over bed	400	600	600	600	750	750
Hole through spindle	50	60	60	60	80	80
Swing over cross slide	215	325	325	325	525	525
No. of spindle speed	8 Speed ranging 28 to 1205 RPM	8 Speed ranging 45 to 1000 RPM			8 Speed ranging 32 to 720 RPM
Gross weight (kgs)	1450	2250	2600	2900	2900	3200
Net weight (kgs)	1150	1860	2050	2300	2600	2900
Power required	3HP x 1400 RPM	5HP x 1400 RPM			7.5HP x 1440 RPM
