LED Display, Packaging Type : RGB

We are offering p10mm led display . Very high-definition display with outstanding image and video quality.
High refresh rate(greater than 400) with software adjustable, suitable for filming,
high grayscale with superior color uniformity
wide viewing angle(greater than 110 ° in horizontal)
low power consumption
high reliability and long lifespan(mtbf more than 10000hours)
ip rating with the back ip43, the front ip65
fast and easy to install and dismantle
with ce,etl,tuv certificates
product feature
very high-definition display with outstanding image and video quality.
High refresh rate(greater than 400) with software adjustable, suitable for filming,
high grayscale with superior color uniformity
wide viewing angle(greater than 110 ° in horizontal)
low power consumption
high reliability and long lifespan(mtbf more than 10000hours)
ip rating with the back ip43, the front ip65
fast and easy to install and dismantle
with ce,etl,tuv certificates
product specification/models
module technical parameters:
- pixel pitch: 10mm
module size: l160×h160×34mm
physical density: 10000dots/sq m
pixel configuration: 1r1g1b (dip346)
driving method: constant current 1/4scan
display resolution: 16×16=256dots
driving device: mbi5024
module port: hub 75
- working voltage: 5v
module consumption: 17w
viewing angle: h110 v50
equilibrium brightness: more than 8000 cd/ sq m
color temperature: 6500k-9500k
gray scale/color: 16.7m color
every square meter module: 39.06pcs
module weight: 0.45kg
