Contact SupplierWe are offering p7mm led screen. Indoor full color led display with p7.62mm
ultra high definition display with vivid image and video quality (with smd instead of dip)
ultra high brightness with low power consumption
high refresh rate with software adjustable, suitable for filming.
Wide viewing angle
fast and easy to install and dismantle.
High reliability and long lifespan
on-site pixel by pixel brightness and color correction bring greater uniformity.
product feature
indoor full color led display with p7.62mm
ultra high definition display with vivid image and video quality (with smd instead of dip)
ultra high brightness with low power consumption
high refresh rate with software adjustable, suitable for filming.
Wide viewing angle
fast and easy to install and dismantle.
High reliability and long lifespan
on-site pixel by pixel brightness and color correction bring greater uniformity.
product specification/models
module technical parameters:
- pixel pitch: 7.62mm
module size: l243.84ã�h121.92ã�15mm
physical density: 17222dots/sq m
pixel configuration: 1r1g1b (smd3528)
driving method: constant current 1/8scan
display resolution: 32ã�16=512dots
driving device: mbi5024
module port: hub 75
- working voltage: 5v
module consumption: 16w
viewing angle: h120 v120
equilibrium brightness: more than 1500 cd/ sq m
color temperature: 6500k-9500k
gray scale/color: more than16.7m color
every square meter module: 33.64pcs
module weight: 0.28kg
display technical parameters:
- option distance: 8-15m
maximum power: 550 w/ sq m
frame frequency: more than 60 hz/s
refresh frequency: more than 400 hz/s
working environment temperature: -20~600c
working environment humidity: 10%~90% rh
input signal: rf \ s-video \ rgb etc
- control system: pctv nonlinearity card + dvi display card + linsn control system
steel box size: l975ã�h9975ã�120mm
life: 100000 hours
display working voltage: ac46~54hz, 220vâ±15%/110vâ±15%
steel box weight: 42 kg/ sq m (standard steel box)
ip rating: the back ip40, the front ip50
payment
30% before production,70% balance before shippment
