LED Screen

We are offering P20mm Led Screen . Outdoor Full color LED Display with P20mm
Very high-definition display with outstanding image and video quality.
High refresh rate(greater than 400Hz) with software adjustable, suitable for filming,
High grayscale with superior color uniformity
Wide viewing angle(greater than 110 ° in horizontal)
Low power consumption
High reliability and long lifespan(MTBF morethan10000hours)
IP rating with the back IP43, the front IP65
Fast and easy to install and dismantle
Product Feature
Outdoor Full color LED Display with P20mm
Very high-definition display with outstanding image and video quality.
High refresh rate(greater than 400Hz) with software adjustable, suitable for filming,
High grayscale with superior color uniformity
Wide viewing angle(greater than 110 ° in horizontal)
Low power consumption
High reliability and long lifespan(MTBF more than10000hours)
IP rating with the back IP43, the front IP65
Fast and easy to install and dismantle
Product Specification/Models
Module technical parameters:
- Pixel pitch: 20mm
Module size: L320×H160×26mm
Physical density: 2500dots/m²
Pixel configuration: 1R1G1B (DIP346)
Driving method: Constant current static duty
Display resolution: 16×8=128dots
Driving device: MBI5024
Module port: HUB 90
- Working voltage: 5V
Module consumption: 23W
Viewing angle: H110 V50
Equilibrium brightness: more than 6500 CD/ m²
Color temperature: 6500K-9500K
Gray scale/color: more than16.7M color
Every square meter module: 19.53pcs
Module weight: 0.78kg
Display technical parameters:
- Option distance: 20-160M
Maximum power: 600 W/ sq m
Frame Frequency: more than 60 HZ/S
Refresh frequency: more than 400 HZ/S
Working environment temperature: -20~600C
Working environment humidity: 10%~90% RH
Input signal: RF\ S-Video\ RGB etc
- Control system: PCTV nonlinearity card + DVI display card + Linsn control system
Steel box size: L1280×H960×140mm
Life: 100000 HOURS
Display working voltage: AC46~54HZ, 220V±15%/110V±15%
Steel box weight: 50 KG/ sq m(standard steel box)
IP rating: The back IP43, The front IP65
Payment
T/T 30% before production,70% before shippment
