Contact SupplierP16mm led sports display:
pixel pitch 16mm
density 3906 pixel/sqm
pixel composing dip546
viewing angle 60(v)/110 (h) degree
brightness 6500 mcd
driving way constant static
control way real pixel
module size 256mm*128mm
cabinet size 1024mm*768mm
cabinet resolution 2304 pixels
cabinet weight 62 kg/sqm
max consumption 1000w/sqm
avg. Consumption 450w/sqm
voltage ac220, 50hz or ac110, 60 hz
best view distance 20~53m
cabinet material iron/aluminum
power supply taiwan meanwell
lifetime >100,000h
working temperature -20°c~+55°c
1. pixel pitch(mm) : 16
2. module size: (mm) 256×128
3. display resolution: 16 pixel× 8 pixel
4. pixel configuration: 2r1g1b
5. density of pixel(dot/m2) 3906
6.multiplied file formats, such as avi, mov, mpg, dat, vob are comprehensive,
and also we have three display mode as vga+vide and vga. There are also interfaces
for sound signal and video signal, includin g cvbs, s-video, vga, dvi, hdmi.
7. Bits controller: 4096 grade grey control system and the color is over 16.7 millions,
and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor,
whose scope is 256 grade.
8. 16 bits controller: the color is over 281 trillions, high brightness, very high contrast.
9. Show all kinds of word, text, graph, picture, video, 2-dimention
