Aluminum alloy LED Street Lamp

MOQ10 Set(s)
MaterialAluminum alloy, steel-based glass mask, heat-resistant silicone seal
Color TemperatureWhite:4000-6500K Warm White:2700-4000K
Working Temperature-20°c -- 45°c
CE&RoHS approved YES
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Product Details

Color TemperatureWhite:4000-6500K Warm White:2700-4000K
Working Temperature-20°c -- 45°c
MaterialAluminum alloy, steel-based glass mask, heat-resistant silicone seal
Input Voltage170~260V AC
MTBF50000 hrs
Protective ClassIP65
Weight10.3kg
Color Index(CRI)≥80
Recommend lamppost height8m
Luninous Flux7200lm
Lamp's Efficiency(%)≥85%
Effective Illuminated Area(Height 6m):20×7m (Height 8m): 25×9m
LED Initial Flux≥7200 Lm
Lighting Angle140, 80
Suitable Temperature≤90%
CE&RoHS approved YES
LED Single Lamp's Efficiency(%)≥90 Lm/W

Solar LED street lamp
Features:
1.Protection class IP65
2.Isolated low-voltage constant current driver, safe, stable and reliable
3. Adopts convection cooling structure, use the high-quality heat dissipation aluminum , extending the life time of the lamp.
4.Strip lighting optical design, to improve the uniformity of road surface, no glare, no strobe
5.Adops imported LED chip as light source, enjoys long life time and friendly lighting environment.
Optical Parametre
Item
Parameter
LED Single Lamp's Efficiency(%)
≥90 Lm/W
LED Initial Flux
≥7200 Lm
Lighting Angle
140, 80
Lamp's Efficiency(%)
≥85%
Color Index(CRI)
≥80
Effective Illuminated Area
(Height 6m):20×7m (Height 8m): 25×9m
(Height 10m): 32×12m (Height 12m): 36×15m
Color Temperature
White:4000-6500K Warm White:2700-4000K
Operating Specification
Item
Parameter
Working Temperature
-20°c -- 45°c
Suitable Temperature
≤90%
Material
Aluminum alloy, steel-based glass mask, heat-resistant silicone seal
MTBF
50000 hrs
Protective Class
IP65
Recommend lamppost height
8m
