Lfiii Type Semi-automatic Crimped Wire Mesh Machine

We are offering lfiii type semi-automatic crimped wire mesh machine.
this machine was a knitting machine that using the long wire diam to crimp the need form.and then to weave the square hole screen in machine. The whole process is simple, the noise is lower, high efficiency, and all the wires that the diam is ￠2mm-￠8mm,and the aperture is 10- 80mm ,the weaving width is 1-2.5m can be weaved. The products are widely used in the filtering of mine.
main technical parameters:
knitting width(m) overall size (m) motive power (kw) weight (kg)
1.0(44") 2.5*2.5*1.5 0.75 1000
1.2(52") 2.8*2.5*1.5 1.1 1200
1.3(56") 3.5*2.5*1.7 1.1 1300
1.5(63") 4*3*1.7 1.5 1400
1.8(75") 4*3*1.7 1.5 1500
2.0(212") 4.2*3*1.8 2.2 1800
2.3(212") 4.2*3*1.8 2.2 2000
