Specifications:
| Model No.1 | Model No.2 | Model No.3 | |
| Size (Length of bad) | 3 1/4’ - 1060 | 4 ½’ - 1370 | 6’ - 1820 |
| Height of center | 165 | 165 | 165 |
| Width of bed | 240 | 240 | 240 |
| Max. Swing over bed | 380 | 380 | 380 |
| Max. Swing in gap | -- | 550 | 550 |
| Admit between center | 450 | 685 | 1200 |
| Lead Screw Dia / Threads | 25.4 x 4 TPI | 25.4 x 4 TPI | 25.4 x 4 TPI |
| Range of Matric Threads | 0.5 to 7 | 0.5 to 7 | 0.5 to 7 |
| Range of Inch Threads | 4 to 48 | 4 to 48 | 4 to 48 |
| Cross Slide Travel | 140 | 140 | 140 |
| Drive V-belt | Double V-Belt C-72 & Flate belt | ||
| Dia of Hole through spindle | 42 | 42 | 42 |
| Spindle Nose Dia / Threads | 61.6 / 8 TPI | 61.6 / 8 TPI | 61.6 / 8 TPI |
| Tail stock spindle Dia / Taer | 38.1 / MT 3 | 38.1 / MT 3 | 38.1 / MT 3 |
| Tail stock spindle Travel | 120 | 120 | 120 |
| Required Powers | 1 H.P. | 1 H.P. | 1 H.P. |
