| Model | IMC-25 | IMC-40 | IMC-50 | IMC-80 | IMC-100 | IMC-120 |
| Max. Pitch Can be Rolled (in mm) | 2.5 | 3.5 | 4.0 | 5.0 | 5.5 | 8 |
| Max. Dia can be Rolled in feed (in mm) | 25 | 40 | 50 | 80 | 100 | 125 |
| Max. Dia can be Through feed (in mm) | 16 | 28 | 35 | 40 | 50 | 70 |
| Max. Rolling Length in feed (in mm) | 80 | 150 | 150 | 150 | 150 | 150 |
| Max. Rolling Length Through feed | Indefinite | Indefinite | Indefinite | Indefinite | Indefinite | Indefinite |
| Max. Outer Dia Thread Rolls (in mm) | 150 | 180 | 200 | 220 | 220 | 220 |
| Spindle Dia (Bore Dia) (in mm) | 54 | 54 | 69.85 | 69.85 | 69.85 | 69.85 |
| Max. Rolling Force | 8 Tons | 13 Tons | 15 Tons | 24 TONS | 30 Tons | 40 Tons |
| Power for Roll Spindles | 3 H.P. 1400 RPM | 5 H.P. 1400 RPM | 7.5 H.P. 1400 RPM | 10 H.P. 1400 RPM | 12. 5 H.P. 1400 RPM | 15 H.P. 1400 RPM |
| Power for Hydraulic Pump | 2 H.P. | 3 H.P. | 5 H.P. | 5 H.P. | 5 H.P. | 7.5 H.P. |
| Power for coolant pump | 0.1 H.P. | 0.1 H.P | 0.1 H.P | 0.1 H.P | 0.1 H.P | 0.1 H.P. |
