Liquid Bottle Filling Machine, Power : 2 H.P / 230 V.AC

Get Latest Price

Machine WeightApprox 600 Kgs
Power2 H.P / 230 V.AC
PhaseSingle Phase
UsageFilling Liquid / Viscous Liquid/ Hot Liquid in to the Bottles /Containers
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Company Information

Shree Bhagwati Machtech India Pvt Ltd.

Rakhial, Ahmedabad, Gujarat

View Number

Member Since 10 Years
Nature of Business Manufacturer
GST No. 24AANCS9768F1ZQ

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

UsageFilling Liquid / Viscous Liquid/ Hot Liquid in to the Bottles /Containers
Machine WeightApprox 600 Kgs
Power2 H.P / 230 V.AC
PhaseSingle Phase
BearingsSKF / Nachi (USA) / Timken (USA)
In let & Out Let PipesSilicon Hose Pipes
SensorsLeuze /Sick / Panasonic
Machine NameAutomatic Piston Liquid Filling Machine
Slat Chain thickness3mm
Volume AdjustmentHMI + PLC (one time setting)
Machine main base frameMild Steel Angles
Hopper SpecificationJacketed with stirrer
Conveyor GuideStainless Steel 304 Rod (10mm Round Bar)
Operating PanelHMI + PLC
Production Speed Per Hour6400 to 7200 containers per hour Speed Depends upon the Number of Filling Heads, Liquid Foaming Nature, Filling Volume, Neck Size)
Wires & CablesLabb
VFD MakeDelta / ABB
HopperStainless Steel 316
Prevention of DroppingPneumatic system
Emergency StopEmergency push button on conveyor
HMI + PLCDelta / Panasonic
Working Height860mm ( +/-50 mm)
Electrical ComponentsABB / Delta /Spectra
Slat Chain Size97mm, Pitch - 3.5”, Stainless Steel 304
PneumaticsSMC / Festo / Janatics
No Bottle – No FillingWith the help of Sensor
Working DirectionLeft to Right - Linear
Machine CoveringsComplete in S.S. 304
Level sensor for hopperLeuze /Sick / Panasonic
ProxyAutonix / Pulset
Air PipesSMC / Festo / Janatics
Material Collection Tray at the bottom of ConveyorStainless Steel 304
Compressed Air Required6 bar pressure 0.5 CFM
Conveyor Motor0.5 HP 1440 RPM Bonfiglioli
Conveyor Motor Make0.5 HP Bonfiglioli
Hopper Capacity200 liters
Filling Volume Accuracy+/-0.5 %
Non Contact PartsStainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable)
Electrical WiringFerrule Numbering on all the wires with Proper Markings
Machine DimensionApprox 12 (L) x 8 (W) x 10 (H) – in Feet
Filling SystemServo base filling
By-Pass PipesSilicon Pipes
Upper and Lower Level for HopperLevel Switch with Sensor
Number of Filling Heads8 Heads
Product Contact PartsStainless Steel 316
ConveyorStainless Steel 304
Plating(Wherever Applicable)Zinc / Hard Chrome / Blackening
Volume Capacity (Range of Syringe)100ml to 1000 ml with help of change parts
Suitable for ProductsFree Flowing Liquids
Machine Motor Make2 KW Delta / Panasonic
Suitable for Packing MaterialHDPE / PET / GLASS / METAL TIN / Aluminum Bottles
Up Down MovementPneumatic system
Conveyor Gear Box MakeBonfiglioli Ratio: 50:1
