Contact Supplier| Max insert depth | L=6m(>6m customize) |
| Max control scope | L-120mm |
| Min control scope | 50mm(<50mm customize) |
| Medium density | > 0.5g/cm3 |
| Working pressure | PN2.5~ PN160(Max pressure PN320) |
| Working temperature | -40~80 oC, -40~120 oC, -40~150 oC (250 oC customize ) |
| Float diameter | D28~D120 (Depending on pressure and density) |
| Installation Type | Flange: DN40~DN150 |
| Flange standard: HG/T20592~2009 | |
(Pressure > PN25, Flange > DN125_ | |
| G2'' thread | |
| Other method (consulting) | |
| Maximum switch frequency | <1 × 105 |
| Error | ±8±2mm |
| Working power supply | 220VAC/380VAC |
| Max voltage of switch | <250 VAC |
| Max current of switch | 5A |
| Installation angle | < ± 25o |
| Wiring box | M20×1.5 female thread |
| Protection grade | IP65 |
| Explosion-proof grade | Exd II CT6Gb |
