Cryocooler based portable Liquid Nitrogen Plants
We provide complete portable Liquid Nitrogen generator/Plant. This is indigenously developed except the cryocooler/refrigerator part. Now you can have Liquid Nitrogen on demand. For pricing and more information on production capacities please contact us. Features of these LN2 plant are listed below.

Produce Liquid Nitrogen directly from the air using advanced PSA or Membrane technology.
Powered by GM Cycle Cryocooler or acoustic Stirling (pulse tube) cryocooler.
100W @80K required for production of 1litre/hr
99% or better purity at nominal operating conditions. The pressure in the storage vessel can be set from 0.3 to 3 bar (g), increasing the liquid nitrogen production to a maximum of 30% at a purity of 98% or better. (refer the wattage at higher boiling points)

Plant model	Capacity	Cryo cooler	Compressor	Electrical power
INDUSLN5	5 Ltrs/day	Patented technology using special Pulse tube Cryocooler	Air cooled	900 Watts, Single phase
INDUSLN8	8 Ltrs/day	GM type cryocooler 40 W@77 K	Water cooled Air cooled	2.6 kW 3.0 kW
INDUSLN40	1.8 Ltrs/hr (~40litres/day)	GM type cryocooler/ acoustic Stirling (Qdrive, pulse tube) 180W@77 K	Water cooled	7 kW (GM type) 4.5 kW (Acoustic Stirling, pulse tube)
INDUSLN80	3. 3Ltrs/hr (~80litres/day)	2X GM cryocooler, 350 W@77 K	2X, Water cooled	14 kW
INDUSLN120	5 Ltrs/hr (~120litres/day)	acoustic Stirling (Qdrive, pulse tube) 500W@77 K	Water cooled	13 kW
INDUSLN240	10 Ltrs/hr (~240litres/day)	acoustic Stirling (Qdrive, pulse tube) 1000W@77 K	Water cooled	24 kW
