We are offering liquid oral manufacturing plant, pharmaceutical machinery
the facility consists of :
sugar syrup vessel
online sugar syrup prefilter
manufacturing vessel
storage vessel
vacuum system for transfer of sugar syrup
filter press inline homogeniser
product piping
control panels
unique features of the facility :
the liquid oral manufacturing plant is designed to be operated by one operator and one helper, saving on precious man-power costs.
Sugar syrup and manufacturing vessels are provided with limpet coils for heating and cooling, designed for internal vacuum to facilitate transfer of sugar directly from stores to sugar syrup vessel.
Sugar syrup is transferred to manufacturing vessel through online sugar syrup prefilter by vacuum.
Entry of all propeller agitators are from bottom through a specially designed cartridge mechanical seal with tctc seal face.
The advantage of the bottom propeller agitator over the conventional agitator is that there are no vibrations of shaft, no couplings in the drive assembly, leading to lower maintenance cost for liquid oral manufacturing plant.
Pipes, pipe fittings and valves are of ss 316, seamless, internally electropolished with din standard unions and silicon gaskets.
Manhole of all the vessels are equipped with davit fitting and the cover of the manhole slides instead of being lifted.
Process control :
values like current, product temperature are displayed digitally on the electrical control panel.
The mechanical seal is equipped with a water circulating system and has a water detection sensor which trips the motor, if the water circulation to the seal is interrupted.
