Load Break Switch

Load Break Switch, for Transformer protection

Listing ID #6331511

Get Latest Price
  • TypeIndoor and outdoor
  • ApplicationTransformer protection, Capacitor bank current switching
  • FeaturesCompact, reliable and proven design, Tripping initiation by fuses, Mechanically interlocked earth switch, Live line indicators for operator safety
  • Ratings12kV/630A/25kA, 24kV/630A/25kA, 36kV/630A/25kA
  • Supply Type Manufacturer, Exporter, Supplier, Distributor, Trader
Preferred Buyer From : All over the world
View More Details
Send Enquiry

Company Information

M/s Megawin Switchgear-P-Limited
Alagapuram, Salem, Tamil Nadu
View Number
  • Member Since 6 Years
  • Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

Description 12kV 24kV 36kV
Rated Current  630A  630A  630A
System Voltage  11kV  22kV  33kV
Rated Voltage  12kV  24kV  36kV
Frequency  50Hz  50Hz  50Hz
No. of Poles  3  3  3
One minute power frequency withstand voltage  28kV RMS  50kV RMS  70kV RMS
Impulse withstand voltage  75kV Peak  125kV Peak  170kV Peak
Rated short time withstand current  25kA / 3 Sec  25kA / 3 Sec  25kA / 3 Sec
Enclosure & Thickness  CRCA min 2mm  CRCA min 2mm  CRCA min 2mm
Degree of protection  IP 55 for Outdoor and IP 4X For Indoor  IP 54 for Outdoor and IP 4X For Indoor  IP 54 for Outdoor and IP 4X For Indoor
Paint shade  RAL 7032  RAL 7032  RAL 7032
Operating mechanism  Quick make, Break, Manual spring Assisted  Quick make, Break, Manual spring Assisted  Quick make, Break, Manual spring Assisted
Protection  HT HRC Fuse  HT HRC Fuse  HT HRC Fuse
