Loop Steamer For Digital Printing

Some important features of the RECKON make Loop Ager Machine:

1. Compact steaming chamber design to reduce steam consumption.

2. Even distribution of steam in chamber, steam being injected from the top and being lighter than

the air will force to remove air and exhaust from bottom will be occupied in the process chamber

fully and thus leaving no chance of air inside the steaming chamber.

3. Optimum steam conditioning and humidification with parallel flow inside the steamer.

4. Conveyor rolls are specially treated with shot blasting which are rotating on their axis to avoid

marking off from the rod itself.

5. Loop formation is done by a Loop Rod roller system.

6. The steaming chamber is closed type made completely in stainless steel.

7. For low temperature steaming the chamber roof and entry, delivery slit is heated by steam coils

preventing condensation and dripping on the fabric.

8. DIGIFIX, ATMOFIX and UNIFIX Steamers are equipped with special device steam saturator that

conditions the steam, it passes through the water before being injected into steaming chamber.

These particular characteristic of steam pre-conditioning which helps prevent and control the

exothermic reaction of the fabric and of the printing paste, make the machine unique and our

Temperature control system/ moisturising system for the said machines are the basis of great

success achieved in the textile industries for Low Temperature Applications.

9. For high temperature steaming the EVOMAX and UNIFIX steamers are equipped with an efficient

re-circulations system and heat exchanger using either thermic fluid or direct gas fire system

which ensure uniform temperature in the chamber.

10. A special system to allow air to re-circulate in our RAPIFIX curing machine instead of steam

permits polymerization treatment with hot air up to 160 ͦC.

11. Two big size access windows are provided on the front side and two small inspection windows on

back side and also one small size window on the Drive arrangement platform.

12. Steam exhaust fan driven by variable speed AC motor, All fabric movements are driven by variable

speed AC motor as well.

13. Automatic control PLC system for programming and monitoring of steam quantity, steam

pressure, process time and temperature are optional with our “PRO” version of all the variants of

Agers and Curing machines.

14. Our “LITE” versions of machines are also available for all variants of Agers and Curing machines for

Manual operations which are also equipped with Modbus protocol and 7” HMI for easy

operations.
