Contact SupplierDetection distance(mm):2mm+_10%
set distance:0~1.6mm
standard detection object:iron 12*12*1mm
response frequency:(n.ptype):0.6khz (d type):0.4khz (a type):25hz
*ã�â equivalent to the same type of the other brands ã�â (p+f and turck)
*ã�â power supply reversal connection protection; short-circuit protection, can directly connect with plc
* newly added current over-load protection; the elements are made of imported chip
*ã�â long service life, high reliability and strong resistance property to environment
*ã�â red led indicates that it's available to detect the sensor operating state
*ã�â full thread shape to enlarge the installation space; can use wrench and clamp directly
*ã�â countermeasure to improve the housing intensity and to solve disconnection
* ip67 protection structure (iec specification).
