| MODEL NO. | SVI-IMG-300 | SVI-IMG-3D | SVI-IMG-5300 |
|---|---|---|---|
| Software | QC-300 | MSU-3DPro | Ik 5000 |
| Measuring Range-Standard | 150mm X 100mm X 100mm | ||
| Measuring Range-Optional | X-axis upto 500mm, Y-axis upto 400mm, Z-axis upto 300mm | ||
| Resolution | 0.005/ 0.001/ 0.0005/ 0.0001mm | ||
| Linear Accuracy | (3+L/200) micron | ||
| Repeatability | ±(0.002mm) | ||
| Vision | 1/3" High Resolution CCD Camera | ||
| Magnification | Optical Magnification 0.7X - 4.5X & Magnification on Monitor 35X - 225X | ||
| Video Edge Detection | Standard | ||
| Optional Hardware | PC + 19" TFT Monitor | ||
| Illumination Surface | Fibre Optic/LED | ||
| Illumination Contour | Halogen Lamp/LED | ||
| Operation | Manual with Quick Release Knob | ||
| Base Platform & Column | Metal Base | ||
| Platform Load Capacity | 15Kg | ||
| Power Supply | 220-240 V ± 5%, 50/60 Hz | ||
| Motion Control through Joystick | Optional | ||
| Programmable Lite Control | Optional | ||
| Touch Probe | Optional | ||
| Non-Linear Error Correction | Optional | Standard | Standard |
| Autofocus | Optional | ||
