50 Hz Galvanized Iron Color Coated Material Handler

₹ 45.25 Lakh - ₹ 1.36 Cr / piece

Surface FinishingColor Coated
MaterialGalvanized Iron
Frequency50 Hz
Packaging TypeBox
Supply TypeManufacturer, Exporter, Supplier, Retailer, Trader
Preferred Buyer Location All Countries Except India

Company Information

Member Since 13 Years
Nature of Business Supplier
Year of Establishment 1997

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Number Of FlowerAir Handlers
MaterialGalvanized Iron
ApplicationCommercial Use, Industrial Use
FeatureCorrosion Resistance, Fine Finished, Good Quality, Rust Proof
Country of Origin220 V, 240 V
ConditionNew
Frequency50 Hz
Packaging TypeBox
Power SourceElectric
Surface FinishingColor Coated
Drive TypeElectric
PhaseThree Phase
BrandMaterial Handler
Size5.5

cheap price hydraulic material handler crawler excavator CNMH18 material handler

Product Description

Item	Unit	Data
Machine weight	t	18
Diesel engine power	kW	91
Rated speed	rpm	1750
Max. flow	L/min	2×140
Max. operation pressure	MPa	30
Swing speed	rpm	13
Travel speed	km/h	3.4
Cycling time of operation	s	15
Working attachment		Data
Boom length	mm	5500
Stick length	mm	3800
Capacity with multi-tine grab	m3	0.6 (5-tines)
Max. grabbing reach	mm	10280
Max. grabbing height	mm	8170
Max. grabbing depth	mm	4680

1. CNCMC material handlers are efficient special equipment for loading and unloading, specially designed for loading and unloading working conditions (including special main valves, special hydraulic systems, etc.), not simple modification from excavators.

2. CNCMC material handler is the latest products in Bonny, it is equipped with the world famous brand hydraulic components. it adopted special undercarriage, enlarge distance between sprocket and idler, and two tracks, largely improve the working stability and elevating capacity; develop the working attachment further, largely improve the operation efficiency under ensuring the working reaching.

3. CNCMC material handlers have several individual scheme combinations between power unit, working attachment, working tools, driver’s cab and undercarriage, can be fully satisfied the personalized requirements of customers.The following advanced systems can be selected individually or in combination as required: Monitoring system with displayer, electronic weighing system, radiation detection system, automatic central lubricating system, rubber track, tools applicable (Multi-tine Grab, Clamshell grab, Wood grab, Hydraulic shear, Hydraulic piler etc.).

4. Applicable for loading, unloading, stacking, transferring and packing in scrap steel yards, wharf yards, railway yards, as well as light material industry.
