convenient for visiting consultants, suitable for general surgical applications and compact and light weight size of the device.
reduced rf distortion in other o.t. Equipments due to noiseless performance.
patient plate monitoring facility, eliminate the risk of site burns.
independent mono polar and bipolar output can be used simultaneously by foot switch and hand both.
all power modes are separately indicated by led indicatiors.
push button selector switch for controlling power intensity and selecting different modes.
digital display for set power intensity for differnet modes.
| mode | sub mode | max.rated load (ohms) | max. Rf power |
monopolar cut | pure blend | 500 � 500 � | 250 w 250 w |
monopolar cut | soft force | 500 � 500 � | 125 w 175 w |
bipolar cut | pure blend | 100 � 100 � | 150 w 100 w |
bipolar coag | soft force | 100 � 100 � | 75 w 100 w |
| input power supply | |
| input power | 180-270v ac |
| current fuse | 7 amps. |
| output control | |
| digital and push switch control in all modes 250 mdd* | |
| safety features : | |
| unit construction | according to iec-6060-2-2 & 60601-1-1. |
| protection class | ii-b. |
| unit type | cf. |
| output | all floating output. |
| nominal frequency | 350 khz |
| high frequency leakage current | |
